Shenzhen Yizhuo Electronics Co.,Ltd has been established in 2012 years, Our factory area more than 5,000 square meters. We have more than 100 workers and 20 employees.We are Aluminum PCB and FR4 PCB
5 Years
| Ask Lasest Price | |
| Brand Name : | Yizhuo |
| Model Number : | led light pcb 01 |
| Certification : | CE,ROHS,UL |
| Payment Terms : | T/T, Western Union |
| Delivery Time : | 10-12 work days |
Power 1W 3W Aluminum LED PCB For SMD Diode Bead Components Series
Detailed Product Description
Materials: | Base Aluminum | Thichkness: | 1.5mm |
|---|---|---|---|
Cu Thickness: | 1oz | Thermal Conductivity: | Customization |
Solder Color: | Black White Green According Customization | Legend: | Customization |
Surface Finished: | LF-HASL OSP |
PCB Type | Material Type | Material Brand | |||||||
Single side pcb | CEM-1 | SY | |||||||
The advantage of us | |||||||||
1 | We have our own, independent of the wastewater treatment system.Make sure there will be a very big development space and the stability of the production environment in the futurer | ||||||||
2 | Flexible operation, can be in the production of small batches.Also can produce large quantities.Can save production quickly. | ||||||||
3 | The urgent double sample production for 24 hours, The urgent Multilayer sample production for 48 hours.completely according to customer requirements | ||||||||
About the Files | |||||||||
1 | You have gerber files or PCB files | ||||||||
2 | You have PCB samples. send to us the sample. we will help for free copy it | ||||||||
How to calculate the price | |||||||||
1 | For example, your double sided PCB size is 100 mm * 200 mm wide, long double sided PCB price is $60 a square meters.So the calculation results 100MM*200MM*$60/1000000=$1.2 | ||||||||
1 inch=25.4mm | |||||||||
About the transportation. | |||||||||
All the quotation does not include the transportation cost | |||||||||
1 | You find a freight forwarding company to help you, When we finished the PCB ,We wiill send to your forwarder company directly .You directly to the transport charges paid to forwarder company | ||||||||
2 | We help you responsible for transport, freight included in the price.According to how much money a kilogram computation. | ||||||||
3 | In order to save costs.The best is you have familiar forwarder company | ||||||||
Established in the year 2014, we “R Square SMD Solution” are a prominent firm that is engaged in manufacturing a wide range of Tube Light Driver And Fixture, Tube Light Housing, LED Tubelight, LED PCB, LED Flood Light, etc. Located in Ahmedabad (Gujarat, India), we are Partnership firm and manufacture the offered products as per the set industry norms. Our valued clients can avail these products from us at reasonable rates. We sell these products under the brand name ‘QLux’. Under the headship of “Miss. Hiral Dhakan” (Sales Manager), we have gained a remarkable and strong position in the market.
Process Capability | ||||||||||||||
Material Type: FR4/Aluminum/Ceramic/CEM-1/Copper/polytef | Cooper thickness: 0.5-12OZ | |||||||||||||
Board Thickness: 0.2-6.0mm | Min hole size: 0.25mm( finished hole size) | |||||||||||||
Min Line Width/spacing:0.08mm | Drilling accuracy:+/-0.05 | |||||||||||||
Max working size:520*620mm(21.25x24.5inch) | Min Inner layer thickness:0.1mm | |||||||||||||
Min thickness Board for HAL surface finished:0.4mm | Certificate: Rohs, Iso9001, UL(in certification) | |||||||||||||
Min thickness 4 layer: 0.4mm | Min thickness 6 layer:0.6mm | |||||||||||||
Min/Max layer count : 1/20 | Lamination evenness :+/-0.05mm | |||||||||||||
Min SMD Pitch : 0.125mm | Min Dam Between Fine Pitch: >0.1mm | |||||||||||||
Layer to Layer registration:<0.1mm | Impedance control:+/-5% | |||||||||||||
Differential impedance:+/-10% | Board bow/twist tolerance:<0.7% | |||||||||||||
Plating spect ratio: <8:1 | Plating COV: <10% | |||||||||||||
Surface Finished: LF-HASL ,Immersion Gold/Tin/Silver ./Plating Gold/OSP, | PTH backlight : 9-9.5 level | |||||||||||||
Solder Mask:Green , Red, Blue,White, Black,Yellow. | Plating extensibility:>15% | |||||||||||||
Why Choose Us
1) Shenzhen Yizhuo Electronics Co.,Ltd has been established in 2012 years, Our factory area more than 5,000 square meters,120 workers
2) We have good quality control systems, including ISO 9001:2008;
3) Our factory has CE, ROHS, UL certification
4) All the components we use are the New & Original;
5) One-stop service can be provided from PCB design, 1-32 layers PCB manufacturing, components sourcing, PCB Assembly, to Fully Product Assembly.
FAQ:
Q1: Do you have any minimum order quantity requirement?
A: no, the sample you just need a minimum of 2 pieces.
Q2. What is needed for PCB PCBA quotation?
A: PCB: Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ,...)
Q3: How about the Shipping cost?
A: The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.
|
|
