Shenzhen Yizhuo Electronics Co.,Ltd has been established in 2012 years, Our factory area more than 5,000 square meters. We have more than 100 workers and 20 employees.We are Aluminum PCB and FR4 PCB
5 Years
| Ask Lasest Price | |
| Brand Name : | Yizhuo |
| Model Number : | single sided pcb01 |
| Certification : | UL,CE,ROHS |
| Payment Terms : | T/T |
| Supply Ability : | 120000 sq.m/per month |
| Delivery Time : | 10-12 work days |
AC175V AC265V DOB Single Layer PCB Design Silkscreen HASL Lead Free
Pcb design AC175V-265V led single-side DOB aluminium pcb circuit board
Type of Alum board | single board, |
Finish Board Thickness | 0.4mm----- 3.0mm |
Copper Thickness | 1 OZ--6 OZ |
Min.Trace Width & Line Spacing | 0.15mm |
Biggest size | 120cm*60cm |
Type for surface treatment | OSP.HASL, Immersion Gold ,Immersion Tin (lead free) |
OSP | 0.20-0.40um |
Thickness of Ni | 2.50-3.50um |
Thickness of Au | 0.05-0.10um |
Thickness of tin | 5-20um |
Thickness of immersion silver | 0.15-0.40um |
Thermal conductivity | 1.0W -----3.0W |
Dielectric Thickness | 50um-150um |
Thermal resistance | 0.05C/W -1.7C/W |
Minimum completed hole dimension | ±0.10mm |
Tolerance for Hole Diameter | ±0.075mm |
Minimum Drilling Hole Diameter | 0.8mm |
Mask between pins | 0.15mm-0.35mm |
Minimum spacing between Pad and Pad | 0.18mm-0.35mm |
Outline tolerance | ±0.10mm |
Minimum thickness for V-cut | 0.25mm |
Do you know aluminum PCB board?
The construction of Hybrid aluminum PCB
In fact, there were few MCPCB guys know the construction of hybrid
aluminium PCB.
Even some of them know this type PCB.
In a ‘Hybrid’ aluminum PCB construction a “Sub-assembly” of a
non-thermal material is processed independently and then bonded to
the aluminum base with thermal materials.
Typical Hybrid aluminum PCB introduces
Due to hybrid aluminium PCB were not used widely, just use by some
high tech companies.
So there were necessary introduce the typical Hybrid aluminum PCB.
The most common construction is a 2-Layer or 4-Layer Sub-assembly
made from conventional FR-4.
The benefit of Hybrid aluminum PCB
When designed with an adequate number of thermal was this
construction is less costly than one composed of all thermally
conductive materials, but still provides superior thermal
performance over a standard FR-4 product.
We offer one-stop service of PCB Fabrication, layout/design, copy (Gerber, BOM), component sourcing, assembly (SMT ), advanced testing, high standard packing, on time delivery and after-sales service.
FAQ:
Q1. What specifications do you need for PCB quotation?
A: We need your PCB Gerber file,board thickness,copper
thickness,surface finishing and quantity to quote you.
Q2. Are you trading company or manufacturer ?
A: We are PCB manufacturer with 12 years experience in this area.
Q3: How about your supply capacity?
A: Our supply capacity is around 2000sqm each day. where our 25 000 sqm factory space hosts R&D, marketing,
